Description
- Our high-pressure water jet pump is built for sewer pipeline cleaning. It clears grease, sludge, sand and blockages inside drain lines. This machine uses pure high-pressure water, with no chemical additives. It is an eco-friendly solution for municipal and industrial drain maintenance.
Parameters
| Main technical parameters | |||
| Water flow | 170 L/min | Pressure | 240 bar |
| Engine drive | Diesel engine | Diesel engine power | 145 kw |
| Pump speed | 405 rpm | Pump stroke | 95 mm |
| Plunger diameter | 45 mm | Gear ratio | 3.65i |
| Dimension | 2900*1700*1700 mm, 2500kg | ||
| 240bar 170LPM standard configuration | |||
| High pressure hose*100M | Stainless steel pipeline cleaning nozzle*3pcs | ||
| Aluminum alloy pipeline cleaning nozzle*lpc | High pressure pump spare parts*1set | ||
| Optional configurations and services | |||
| Ground trolley cleaning device/large pipeline rotating nozzle/tugboat nozzle, etc. | |||
- The high pressure pump introduces Germany WOMA advanced technology, vertical stainless steel pump head, stainless steel nickel plated alloy plunger, forced cold water cooling.
- High pressure pump box material ductile iron, good heat dissipation, hard texture, not easy to deformation.
- The power end adopts splash lubrication or forced lubrication, stable and reliable transmission, reducing friction coefficient and improving lubricity.
- Pure high-pressure water cleaning, no need to add any chemical agents, no pollution, is the national advocacy and promotion of green high-tech products.
Advantages
- Efficient dredging ability:
- 240 bar pressure powerfully flushes blockages. It works on municipal pipelines, as well as more serious blockages in industrial and commercial sites. This machine resolves tough sewer pipeline cleaning tasks effectively.
- Large flow design:
- 170 L/min flow rate ensures fast flushing. It quickly washes away debris already dredged from the line. It reduces stagnation during work and improves overall cleaning efficiency.
